Bluetooth ESC Designed for Ultimate Performance
The Cayote Crest 8 Evo 1/8 200A Sensored Brushless ESC is engineered for high-performance RC applications, delivering precise power control, reliability, and up to 10% more peak power for an extra edge on the track. Built with reverse polarity protection, it safeguards your system from wiring errors while maintaining consistent performance. With advanced cooling technology, customizable settings, and an included glitch buster to smooth out voltage fluctuations, the Crest 8 Evo adapts seamlessly to any racing condition. Whether you're chasing podium finishes or pushing through rugged terrain, this ESC provides the control, protection, and durability demanded by serious competitors.
About the Crest 8 Evo Brushless ESC
Powerful Boost & Turbo Timing
Featuring a super large 48° boost and turbo timing, the Crest 8 Evo ESC maximizes power output while optimizing motor efficiency. This advanced timing system enhances acceleration and top speed, making it ideal for competitive racing. The fine-tuned performance ensures smoother throttle response and increased stability during high-speed runs.
Bluetooth & Data Monitoring
"With offline data recording, users can track ESC performance and analyze key metrics to improve their driving strategy. This function allows racers to make precise adjustments based on real-time data, optimizing power output and battery usage. The ESC's built-in Bluetooth enables seamless wireless monitoring and tuning. Users can review recorded data via the Cayote Team app or the Xlink Multifunction LCD Program Box (CYECPB01 - sold separately)* to fine-tune their setup for consistent and reliable results."
Reverse Polarity Protection & Full Parameter Tuning
Equipped with over thirty-seven adjustable parameters, the Crest 8 Evo ESC offers extensive tuning options to match various racing styles. Multiple protection functions, such as low voltage and motor overheat protection safeguards your electronics from damage. The built-in Reverse polarity protection system ensures you don't pop it before the first race, making it a reliable choice for stressful racing conditions.
Features:
Built-in Bluetooth compatibility with the Cayote Team app
10% More Peak Power!
Offline data recording for performance tracking
Reverse polarity protection
High-performance ARM architecture - 32-bit industrial- grade Cortex-M4 core
up to 108 MHz clock speed - 5x computing power improvement
1-20 Adjustable drag break
Multiple protection functions for long-term reliability
Optional RPM limiting 10-88K RPM
Throttle Midpoint: 4%, 6%, 8%, or 10%
Includes:
(1) Crest 8 Evo 1/8 200A Sensored Brushless ESC
(1) Sensor Cable
(3) Black 10AWG Wire Connectors
(1) Black 13AWG Wire Connector
(1) Red 13AWG Wire Connector
(1) Heat Shrink Tube Set
(1) Double-Sided Mounting Tape
Instruction Manual
Specifications:
Suggested Application 1/8 Buggies, Truggies & Trucks
Motor Type Brushless - Sensored/Sensorless
Input Voltage 2-4S LiPo (7.4-14.8V)
Continuous Current 200A
Peak Current 1080A
Dimensions (LxWxH) 2.24x1.64x1.57in (56.8x41.6x40mm)
Weight 4.3oz (122g)
Motor Limits 4268/4274 3000kV Maximum with 4S Lipo
BEC Voltage 6.0/7.4V
BEC Continuous Current 8A
BEC Peak Current 12A
Motor Connector Solder
Battery Connector Solder
Motor Wire 10AWG
Battery Wire 13AWG
Throttle Wire -
Programmable Yes, with Cayote Xlink Program Box or Cayote Team App
