● Double Channel, Double Convenience，Small volume, super high power density
● The maximum output is 500W, and the output current is 15A per channel
● Optimize Heat Dissipation, New heat dispersing system dissipating high power heat in time
● IPS Display, Wide View, 650,000 full color, 240×320 resolution
● New clean UI, Designed for charging, more intuitive and simple
● Integrated USB Interface, 5V output for mobile phone charging, with M6D firmware upgrade
SPEC
Input
7.0-28.0V @MAX 30A
Battery type
LiPo LiHV LiFe Lilon@1-6S
NiMH @1-16S Pb @1-10S
Balance current
800mA @2-6S
Balance accuracy
< 0.005V
Voltage range
0.2-5.0V @1-6S
Internal resistance
1-100mR @1-6S
Charge power
500W @MAX 25A SYNC
250W @MAX 15A×2 ASYC
Discharge power
500W @MAX 15A Recycle
12W @MAX 3A Normal
USB
2.1A @5.0V
[email protected]
Product size
98*68*35 mm
Product wight
220g
Pack size
108×80×46 mm
Pack wight
300g
LCD
IPS 2.4″ LCD 320×240 px
In the Box
M6D Charger × 1, USB-C Cable × 1, Quick Manual × 1
